The Equipment was provided as per with Standard Industry Design Practices.

Bar Screen :-   FairField Model CHFF,MACH-03,Primarily Constructed Of Type 316 Stainless Steel,And Designed as Follows:-

• Channel Width : 7' - 0" ft.
• Channel Depth (Max): 5' - 9" ft.
• Lift : approx . 11' - 0" .
• Bar Rack Angle Of Incline : 75 Degrees
• Bar Spacing : 1/4" Clear Openings
• Bars : 0.31" x 0.15" x 1.57" Trapezoidal.
• Peak Flow Capacity : 37.5 MGD

The Equipment was provided as per with Standard Industry Design Practices.

(1) Bar Screen :-   FairField Model CHFF,MACH-03,Primarily Constructed Of Type 304 Stainless Steel,And Designed as Follows:-

• Channel Width : 3' - 0" ft.
• Channel Depth : 6' - 0" ft.
• Lift : approx . 12' - 0" .
• Bar Rack Angle Of Incline : 80 Degrees
• Bar Spacing : 1/4" Clear Openings
• Bars : 0.31" x 0.15" x 1.57" Trapezoidal.
• Peak Flow Capacity : 19 MGD

The Equipment was provided as per with Standard Industry Design Practices.

(1) Bar Screen :-   FairField Model CHFFM,MACH-03,Primarily Constructed Of Type 304 Stainless Steel,And Designed as Follows:-

• Channel Width : 4'- 0" ft.
• Channel Depth : 12' - 0" ft.
• Lift : approx . 17' - 0" .
• Bar Rack Angle : 85 Degrees
• Bar Spacing : 3/4"
• Bars : 0.31" x 0.15" x 1.57" Trapezoidal. Type 304 Satainless Steel
• Peak Flow Capacity : 8.25 MGD

The Equipment was provided as per with Standard Industry Design Practices.

(2) Bar Screen :-   FairField Model CHFFM,MACH-03,Primarily Constructed Of Type 304 Stainless Steel,And Designed as Follows:-

• Channel Width : 4' 0" ft.
• Channel Depth : 10' 8 3/4" ft.
• Lift : approx . 16' - 0" .
• Discharge Height : approx . 4' - 0".
• Bar Rack Angle Of Incline : 80 Degrees
• Bar Spacing : 1/4" Clear Openings
• Bars : 0.31" x 0.15" x 1.57" Trapezoidal.
• Peak Flow Capacity : 20 MGD
